GitHub Copilot API Request Format: Headers and Payload Guide

Developer integrations attempting to interact directly with the GitHub Copilot API will fail if they treat it like a standard LLM provider that accepts static, long-lived API keys. The Copilot API enforces a strict, multi-layered authentication architecture that separates user authorization from model inference through short-lived session tokens. Custom tooling, custom IDE extensions, and automated agent environments must replicate the exact device authorization flow and token exchange choreography to communicate with Copilot's model endpoints without connection drops.

This security model is designed to protect repository source code and audit user activity. Standard static API keys are vulnerable to leakage, as they are frequently committed to public repositories by accident or cached in insecure build logs. By requiring OAuth-based tokens that must be renewed frequently, GitHub limits the exposure window of any single credential. When an editor extension or an agent requests a code completion, it must present a valid session token obtained from the GitHub authentication service.

This token exchange mechanism splits the architecture into two distinct components: the identity provider and the completion provider. The identity provider is GitHub, which validates the developer's credentials or organization membership. The completion provider is the Copilot service, which accepts the temporary session token to generate code suggestions. Organization administrators can also configure Bring Your Own Key settings to connect custom models, but user access is always mediated through GitHub's secure permission systems.

To establish a connection, the local development client first checks for stored credentials in the local system configuration or environment variables. If a valid GitHub token is available, the client initiates a GET request to the internal GitHub Copilot token endpoint at https://api.github.com/copilot_internal/v2/token. This request contains the user's GitHub token in the authorization header. The GitHub authentication service verifies the token scopes and checks if the associated account has an active Copilot subscription. If verified, the endpoint returns a JSON payload containing a temporary session token, typically prefixed with transaction details, alongside an expiration timestamp. The local client uses this temporary token to authorize completions directly with the model gateway. The session token expires after a short duration, requiring the client to request a new token automatically. Caching this session token is critical to avoid rate-limiting issues on the GitHub API, as organizations are subject to standard API request limits.

• How to Use the Manus AI API for Agent TasksFiles uploaded through the Manus API are automatically deleted 48 hours after upload, so production integrations need...
• How to Use the Claude Code API and Agent SDKThe Claude Code Agent SDK gives developers the same tools, agent loop, and context management that power Claude Code,...
• GitHub Copilot API Key: Authentication and SDK Setup GuideA comprehensive developer guide to GitHub Copilot's authentication architecture. Learn why Copilot avoids static API...
• How to Query the GitHub Copilot API with External Tool ContextQuerying the Copilot API with external context allows developers to pass custom file systems, test outputs, and...
• GitHub Copilot API Developer Guide: Uptime, Metrics, and Agent IntegrationAn in-depth developer guide to the GitHub Copilot REST API. Learn how to manage seats programmatically, download daily...
• How to Ground GitHub Copilot with GitHub API DocumentationGrounding GitHub Copilot with the official GitHub API documentation ensures that the assistant generates up-to-date and...

More on this subject: GitHub Copilot (130 guides)

Once a client has retrieved a valid session token, it must structure its HTTP request headers according to GitHub's specific REST API conventions. Outbound requests to the completions endpoint require a combination of authorization details, content type specifications, and version parameters. Failing to supply the correct version parameters will cause the request to default to an older API version, which might not support the desired models or capabilities. Requests without the X-GitHub-Api-Version header will default to use the 2022-11-28 version. Specifying the version ensures that your integration remains stable even when breaking changes are introduced to the API.

To make a successful request to the model gateway, the client must include the following headers:

• Authorization: Bearer <session_token> (The temporary session token retrieved from the token endpoint)

• Content-Type: application/json (Required for all POST requests containing a JSON payload)

• X-GitHub-Api-Version: 2022-11-28 (Explicitly defines the API version to prevent default fallback issues)

• Copilot-Integration-Id: vscode-chat (Or a similar editor identifier that identifies the client plugin)

• Editor-Version: vscode/1.98.0 (Identifies the version of the editor host application)

• Editor-Plugin-Version: copilot-chat/0.23.2 (Identifies the specific version of the Copilot plugin)

• User-Agent: GitHubCopilotChat/0.23.2 (Identifies the client agent making the request)

Here is a complete cURL command demonstrating how to format these headers for a chat completions request:

curl -X POST https://api.githubcopilot.com/chat/completions \
  -H "Authorization: Bearer tid_12345abcdef" \
  -H "Content-Type: application/json" \
  -H "X-GitHub-Api-Version: 2022-11-28" \
  -H "Copilot-Integration-Id: vscode-chat" \
  -H "Editor-Version: vscode/1.98.0" \
  -H "Editor-Plugin-Version: copilot-chat/0.23.2" \
  -d '{
    "messages": [{"role": "user", "content": "Explain binary search."}],
    "model": "gpt-4o",
    "stream": false
  }'

The model gateway uses these headers to route the request, enforce rate limits, and select the correct inference environment. If the client makes request formatting errors, the API returns standard HTTP status codes, such as 401 Unauthorized for token issues or 400 Bad Request for missing headers.

Manage Copilot API request formats in Fastio

Connect your custom integrations and coordinate your agents using the correct GitHub Copilot API request format in a shared workspace. Starts with a 14-day trial, credit card required.

Start 14-Day Trial

The request body sent to the GitHub Copilot model gateway must be structured as a JSON payload that mirrors the OpenAI Chat Completions API specification. This ensures compatibility with standard completions libraries and allows developers to adapt existing LLM client code with minimal changes. The payload configuration varies depending on whether the client is requesting single-line code suggestions or participating in an interactive chat session.

For chat completions, the primary parameter is the messages array, which holds the dialogue history. Each message object in the array must specify a role (such as system, user, or assistant) and the text content of the message. The gateway also accepts optional parameters to control model behavior and output characteristics. Developers configure parameters like temperature to control randomness, max tokens to set limit on response length, and stream to enable server-sent events. Here is a typical JSON payload structure for an interactive chat request:

{
  "model": "gpt-4o",
  "messages": [
    {
      "role": "system",
      "content": "You are a helpful coding assistant."
    },
    {
      "role": "user",
      "content": "How do I reverse a linked list in Python?"
    }
  ],
  "stream": true,
  "temperature": 0.2,
  "max_tokens": 1000
}

When the payload requests streaming, the gateway responds with chunked data transfer. The connection remains open while the model writes response tokens, using Server-Sent Events (SSE) to send data chunks. Each chunk contains a JSON string with the delta of the generated tokens, letting the client render the response in real time. If streaming is disabled, the gateway waits until the complete response is generated before returning a single, consolidated JSON payload.

When building custom Copilot Extensions or developer agents that receive events from Copilot Chat, implementing request verification is a critical security requirement. Because your extension runs as an HTTP service exposed to the web, you must ensure that incoming requests originate from GitHub and have not been tampered with. GitHub signs every outbound request to your extension using an Elliptic Curve Digital Signature Algorithm (ECDSA) with a P-256 curve over the raw request body.

To verify requests, your server must parse specific headers and retrieve GitHub's public verification keys dynamically. GitHub includes two headers in every request sent to your service:

• X-GitHub-Public-Key-Identifier (The identifier of the key used to sign the request)

• X-GitHub-Public-Key-Signature (The base64-encoded ECDSA P-256 signature)

Your verification middleware must perform the following steps:

1. Extract the key identifier and signature from the incoming headers.

2. Fetch the current list of verification keys from the GitHub public endpoint at https://api.github.com/meta/public_keys/copilot_api.

3. Find the key matching the header's identifier and convert it to a usable PEM public key format.

4. Verify the signature against the raw, unparsed request body using the ECDSA P-256 algorithm.

Here is an example Node.js function demonstrating how to perform this signature verification using the native node:crypto module:

import crypto from "node:crypto";

function verifyGithubSignature(
  rawBody,
  signature,
  publicKeyPem
) {
  const verifier = crypto.createVerify("SHA256");
  verifier.update(rawBody);
  return verifier.verify(
    {
      key: publicKeyPem,
      dsaEncoding: "ieee-p1363"
    },
    Buffer.from(signature, "base64")
  );
}

To prevent timing attacks and avoid fetching keys on every request, your service should cache the public keys in memory. If a request carries a key identifier that is not in your cache, your service should fetch the keys again to handle key rotations. If verification fails, your middleware must return an HTTP 401 Unauthorized status immediately and stop processing the request.
