How to Upload Large Files with Microsoft Graph API Using Resumable Sessions

Direct single-request HTTP uploads collapse under real-world network conditions whenever file payloads exceed modest sizes. Microsoft Graph simple PUT calls cap out at 250 MB, rejecting any payload exceeding this single-request limit with a 413 Payload Too Large status code. Even well below that ceiling, uploading files through a single atomic request across unstable connections introduces severe reliability hazards. When developer tools, ingestion pipelines, or automated background workers attempt to stream multi-gigabyte files through a standard HTTP PUT, any socket reset or transient network timeout terminates the connection immediately. Because the server treats the request as an atomic unit, it discards every previously transmitted byte, requiring the client to restart the entire transfer from byte zero.

The Microsoft Graph large file upload API uses resumable upload sessions to transfer files up to 250 GB by slicing binary data into sequential byte ranges aligned to 320 KiB increments. Instead of keeping a single long-lived TCP socket open across the entire transfer duration, your application establishes a session, receives a temporary pre-authenticated upload endpoint, and transmits the binary payload in discrete, manageable chunks. If a packet drop or socket reset interrupts chunk transmission, the client queries the upload session status, inspects the missing byte ranges, and resumes transmission from the exact point of interruption.

Why Direct PUT Requests Break at Scale

Simple uploads in Microsoft Graph send the raw binary payload directly to PUT /drives/{drive-id}/items/{parent-id}:/{filename}:/content, as outlined in the Microsoft Graph driveItem put content documentation. While suitable for small documents, configuration files, and lightweight images, this route introduces three architectural constraints:

1. Payload Size Hard Ceiling: Single-request PUT requests cannot exceed 250 MB. Larger files, such as container images, high-resolution media, raw database dumps, or virtual machine images, are rejected by the API gateway before processing begins.
2. Absence of Socket Resumability: The simple PUT endpoint lacks state-tracking infrastructure for in-flight streams. If a connection drops after sending most of an in-flight file, the API drops the socket and discards the received buffer. The client application has no mechanism to resume transmission from the point of interruption.
3. Gateway and Reverse Proxy Timeouts: Enterprise networks, firewalls, and corporate reverse proxies enforce maximum idle connection limits and socket lifetimes. Uploading a massive file over an uplink with variable bandwidth frequently breaches these timeouts, triggering intermediate proxy drops.

Core Lifecycle of a Graph Resumable Session

To transfer large files reliably to OneDrive for Business, personal OneDrive, or SharePoint Online document libraries, applications follow a structured four-stage resumable sequence:

1. Session Creation: Send an authenticated POST request to createUploadSession targeting the desired drive path. The response supplies an opaque, pre-authenticated uploadUrl and an expiration timestamp.
2. Chunk Geometry Calculation: Partition the local file into sequential byte segments. Each intermediate fragment size must align to an exact multiple of 320 KiB.
3. Sequential Fragment Upload: Transmit each chunk via HTTP PUT requests to the temporary uploadUrl. In this stage, the client specifies the exact byte range in the Content-Range header and omits the standard Authorization bearer token.
4. Commit and Completion Verification: The server returns 202 Accepted containing the next expected byte ranges after each intermediate chunk. When the final byte chunk is accepted, Microsoft Graph commits the file into the document library and returns a 201 Created or 200 OK response with full item metadata.

• How to Upload Files to Dropbox via API: Simple vs Upload SessionsChoosing how to use the Dropbox API to upload file contents depends on asset size and network reliability. The Dropbox...
• How to Download Files via OneDrive API: Microsoft Graph GuideDownloading a file via the OneDrive API requires requesting the binary stream from a driveItem content endpoint using...
• How to Upload Files to OneDrive via API: Simple PUT vs Upload SessionsUploading files to OneDrive through the Microsoft Graph API requires selecting between simple PUT requests and...
• How to Upload Files: Fastio API File Upload TutorialFollowing a Fastio API file upload tutorial is the fast way to get your applications talking to intelligent agent...
• ChatGPT File Upload Limits: How to Handle Large Files and FoldersChatGPT limits file uploads to 512MB per file with total storage limits per user, creating problems for large datasets.
• Google AI Studio File Upload Limits: File API Constraints and Large CorporaGoogle AI Studio and the Gemini File API enforce a 2 GB per-file upload limit and a 20 GB total project storage cap,...

More on this subject: Agent File and Document Workflows (298 guides)

Initiating an upload session requires an authenticated POST request to the Microsoft Graph API, as specified in the official Microsoft Graph createUploadSession documentation. The specific URL path depends on whether you are writing to a user drive, a shared document library in SharePoint, or an existing item.

Target Endpoints Across Drive Hierarchies

Select the endpoint path corresponding to your storage location:

• Current User OneDrive: POST https://graph.microsoft.com/v1.0/me/drive/items/{parent-item-id}:/{filename}:/createUploadSession
• Specific User Drive by ID: POST https://graph.microsoft.com/v1.0/users/{user-id}/drive/items/{parent-item-id}:/{filename}:/createUploadSession
• SharePoint Document Library: POST https://graph.microsoft.com/v1.0/sites/{site-id}/drive/items/{parent-item-id}:/{filename}:/createUploadSession
• Microsoft 365 Group Drive: POST https://graph.microsoft.com/v1.0/groups/{group-id}/drive/items/{parent-item-id}:/{filename}:/createUploadSession
• Direct Drive Target by ID: POST https://graph.microsoft.com/v1.0/drives/{drive-id}/items/{parent-item-id}:/{filename}:/createUploadSession

If you intend to overwrite the binary content of an existing file rather than create a new item under a folder, target the item ID directly:

POST https://graph.microsoft.com/v1.0/drives/{drive-id}/items/{existing-item-id}/createUploadSession

Request Configuration and Conflict Behavior

The session creation request requires an Authorization: Bearer {token} header containing an access token with delegated or application permissions such as Files.ReadWrite or Files.ReadWrite.All.

While the request body is optional, production implementations should pass an item object specifying the desired conflict resolution strategy using the @microsoft.graph.conflictBehavior parameter:

{
  "item": {
    "@microsoft.graph.conflictBehavior": "rename",
    "name": "large-dataset-archive.tar.gz",
    "description": "Quarterly telemetry export"
  },
  "deferCommit": false
}

The conflict behavior property accepts three values:

• fail: Rejects the upload session if an item with the same name already exists in the target folder.
• replace: Overwrites the existing file upon successful completion of the upload session.
• rename: Appends a numerical suffix to the filename if a collision exists, preventing unintentional data loss.

Inspecting the Session Creation Response

When the request succeeds, Microsoft Graph responds with 200 OK and returns a session descriptor:

{
  "@odata.context": "https://graph.microsoft.com/v1.0/$metadata#microsoft.graph.uploadSession",
  "uploadUrl": "https://sn3302.up.1drv.com/up/fe6143a4933a7e/.../upload_session_token",
  "expirationDateTime": "2026-10-12T14:30:00.000Z",
  "nextExpectedRanges": [
    "0-"
  ]
}

The returned uploadUrl is an opaque, pre-authenticated URL. It embeds the necessary routing and credential signatures within its query parameters. Applications must persist this URL for the duration of the upload process. The expirationDateTime field indicates when the session will be discarded by Microsoft Graph, typically giving clients up to 24 hours to complete the file transfer.

Once your application obtains the uploadUrl, it must partition the binary file into sequential byte segments. Calculating chunk geometry correctly is where most custom implementations encounter unexpected failures.

The 320 KiB Alignment Requirement

Microsoft Graph enforces a strict chunking constraint: upload chunk sizes must be multiples of 320 KiB or 327,680 bytes to avoid commit errors. The only exception to this rule is the final chunk of the file, which carries the remaining bytes regardless of whether its size divides evenly by 327,680.

A single 320 KiB fragment represents 327,680 bytes. Common chunk multiples include:

• 10 multiples (3.125 MiB): 3,276,800 bytes
• 16 multiples (5.0 MiB): 5,242,880 bytes
• 32 multiples (10.0 MiB): 10,485,760 bytes
• 64 multiples (20.0 MiB): 20,971,520 bytes
• 192 multiples (60.0 MiB): 62,914,560 bytes

While Microsoft Graph allows chunk sizes up to 60 MiB, selecting an optimal chunk size involves balancing network throughput against retry overhead. On stable cloud infrastructure, a 10 MiB or 20 MiB fragment size minimizes HTTP round trips. On consumer broadband or mobile uplinks, smaller fragments such as 5 MiB isolate network interruptions to smaller byte ranges, preventing excessive retransmission.

Required HTTP Headers for Fragment Uploads

When transmitting a fragment to the uploadUrl, clients issue an HTTP PUT request with specific headers:

• Content-Length: The exact size of the current chunk in bytes.
• Content-Range: The byte range formatted as bytes {start}-{end}/{total_file_size}. Both start and end are zero-indexed, inclusive offsets. For example, the first chunk of a file uses bytes 0-10485759/100000000 when transmitting ten megabytes.

Important Header Rule: Omit the Authorization header when sending chunk PUT requests to the uploadUrl. Because the uploadUrl is already signed and pre-authenticated, including your Azure AD or Entra ID Bearer token can cause authentication rejections or signature verification conflicts on the storage endpoint.

Node.js Implementation for Chunked Uploads

The following Node.js script demonstrates session initialization, byte slicing, header formatting, and sequential transmission using standard runtime APIs:

import fs from "fs";
import path from "path";

async function uploadLargeFileToOneDrive(accessToken, driveId, parentFolderId, localFilePath) {
  const stats = fs.statSync(localFilePath);
  const fileSize = stats.size;
  const fileName = path.basename(localFilePath);
  const sessionEndpoint = `https://graph.microsoft.com/v1.0/drives/${driveId}/items/${parentFolderId}:/${fileName}:/createUploadSession`;
  const sessionResponse = await fetch(sessionEndpoint, {
    method: "POST",
    headers: {
      "Authorization": `Bearer ${accessToken}`,
      "Content-Type": "application/json"
    },
    body: JSON.stringify({
      item: {
        "@microsoft.graph.conflictBehavior": "rename",
        name: fileName
      }
    })
  });
  if (!sessionResponse.ok) {
    throw new Error(`Failed to create upload session: ${sessionResponse.statusText}`);
  }
  const { uploadUrl } = await sessionResponse.json();
  const chunkSize = 327680 * 32; // 10,485,760 bytes (32 multiples of 320 KiB)
  const fileDescriptor = fs.openSync(localFilePath, "r");
  const buffer = Buffer.alloc(chunkSize);
  let startByte = 0;
  try {
    while (startByte < fileSize) {
      const bytesRead = fs.readSync(fileDescriptor, buffer, 0, chunkSize, startByte);
      const endByte = startByte + bytesRead - 1;
      const chunkData = buffer.subarray(0, bytesRead);
      const chunkResponse = await fetch(uploadUrl, {
        method: "PUT",
        headers: {
          "Content-Length": String(bytesRead),
          "Content-Range": `bytes ${startByte}-${endByte}/${fileSize}`
        },
        body: chunkData
      });
      if (chunkResponse.status === 202) {
        startByte = endByte + 1;
      } else if (chunkResponse.status === 200 || chunkResponse.status === 201) {
        return await chunkResponse.json();
      } else {
        throw new Error(`Chunk upload failed: ${chunkResponse.status} ${chunkResponse.statusText}`);
      }
    }
  } finally {
    fs.closeSync(fileDescriptor);
  }
}

Each chunk upload returns 202 Accepted containing a nextExpectedRanges array, confirming which byte ranges the server has persisted to disk.

Accelerate Microsoft Storage Workflows for AI Agents

Sync OneDrive and SharePoint folders into persistent workspaces with built-in hybrid search and remote MCP tooling. Every monthly plan starts with a 14-day free trial that requires a credit card.

Start 14-Day Trial

Network connections over the public internet encounter transient packet drops, TCP resets, and router reboots. The primary architectural benefit of Microsoft Graph upload sessions is the ability to recover gracefully without restarting the upload from the beginning.

Querying Session Status to Resume Transfers

If an HTTP connection drops during chunk transmission, your client should not start over or create a new session. Instead, query the existing session status by issuing an empty HTTP GET request directly to the uploadUrl:

GET https://sn3302.up.1drv.com/up/fe6143a4933a7e/.../upload_session_token

Like the chunk upload requests, this status query does not require an Authorization header. The server responds with a 200 OK status containing the current upload state:

{
  "expirationDateTime": "2026-10-12T14:30:00.000Z",
  "nextExpectedRanges": [
    "20971520-104857599"
  ]
}

The nextExpectedRanges array lists the byte positions that the server is currently waiting to receive. The client parses the first number in the range (in this case, 20971520), seeks to that exact byte offset in the source file, and resumes uploading subsequent chunks.

Common Error Codes and Recovery Strategies

When implementing production upload clients, prepare for specific HTTP status codes:

• 404 Not Found: Indicates that the upload session has expired or was already committed. When a 404 occurs mid-transfer, recovery is impossible; your application must create a fresh upload session and transmit the file from byte zero.
• 409 Conflict: Occurs if another process modified or created a file with the same name during the upload window, and conflict behavior was set to fail.
• 429 Too Many Requests: Microsoft Graph enforces dynamic request rate limits. When your client receives a 429, inspect the Retry-After response header, pause execution for the designated number of seconds, and retry the request using exponential backoff with random jitter.
• 500, 502, 503, 504 Gateway Errors: Transient server or infrastructure faults. Query the session status to confirm which byte ranges were successfully committed before retrying the failed chunk.

Cancelling and Deleting Upload Sessions

If a user cancels an upload, or if an ingestion worker encounters an unrecoverable local error, release the server-side storage allocation by deleting the session:

DELETE https://sn3302.up.1drv.com/up/fe6143a4933a7e/.../upload_session_token

Microsoft Graph deletes the temporary staging file and returns 204 No Content. Proactively deleting abandoned sessions prevents quota consumption and frees staging storage in your tenant.
