MCP Server Architecture: How Model Context Protocol Servers Work

MCP uses a client-host-server model inspired by the Language Server Protocol (LSP) that standardized IDE tooling. The design separates concerns into three distinct roles that communicate over JSON-RPC 2.0.

Host is the AI application the user interacts with, such as Claude Desktop, Cursor, or a custom chat interface. The host process creates and manages multiple MCP clients, controls their lifecycle, enforces security policies, and aggregates context from all connected servers before passing it to the LLM. A single host might connect to a filesystem server, a database server, and a cloud API server simultaneously.

Client is an internal connector that the host creates for each server connection. Every client maintains exactly one stateful session with one server. It handles protocol negotiation, routes messages in both directions, and enforces isolation between servers. This 1:1 mapping is intentional: servers cannot see each other's data, and the host controls what context flows where.

Server is an external process that exposes capabilities through MCP's standardized primitives. Servers can run locally as subprocesses or remotely as HTTP services. Each server focuses on a specific domain, whether that is file access, database queries, or API integrations, and declares exactly what it can do during initialization.

This separation means adding a new capability to your AI system is just connecting another server. The host already knows how to aggregate context from multiple sources, and each server stays simple because it only needs to implement its own domain logic.

Every MCP server exposes its functionality through three primitives, and the client discovers what is available through a structured initialization handshake.

Tools

Tools are functions that the AI model can call. A tool has a name, a JSON Schema describing its inputs, and optional annotations that hint at its behavior (read-only vs. destructive, for example). When the model decides it needs to call a tool, the host sends the request through the client to the appropriate server. Common examples include running a database query, creating a file, or calling an external API.

Resources

Resources are read-only data that the server makes available. Unlike tools, resources are not invoked by the model. Instead, they represent context that the host can attach to a conversation: file contents, configuration values, live metrics, or any structured data the server wants to surface. Resources can be listed, read by URI, and optionally subscribed to for change notifications.

Prompts

Prompts are pre-built templates that guide specific workflows. A server might expose a "summarize-document" prompt that structures the right context and instructions for a particular task. Prompts are user-facing: the host presents them as actions the user can trigger, and they can include embedded resource references and tool calls.

The Initialization Handshake

When a client connects to a server, both sides exchange capabilities. The client sends an InitializeRequest declaring what it supports (sampling, notification handling, root directories). The server responds with its own capabilities: which primitives it offers, whether it supports subscriptions, and what protocol extensions it understands. Only after this handshake completes does the session become active. Both sides must respect the declared capabilities for the duration of the session.

This negotiation means servers and clients can evolve independently. A server can add tool support without breaking clients that only use resources, and a client can add sampling support without requiring all servers to understand it.

MCP defines two standard transports, and the choice between them depends on where your server runs relative to the client.

stdio for Local Servers

The stdio transport is the simplest option. The client launches the server as a child process and communicates by writing JSON-RPC messages to the server's stdin and reading responses from stdout. Messages are newline-delimited, one per line. The server can write logs to stderr without interfering with the protocol.

stdio is the right choice when the server runs on the same machine as the host. It has zero network overhead, needs no authentication (the OS provides process-level isolation), and starts instantly. Most development tool integrations, filesystem servers, and local database connectors use stdio. The downside is that it cannot scale beyond a single client connection, and the server lifecycle is tied to the host process.

Streamable HTTP for Remote Servers

Streamable HTTP is the current recommended transport for remote servers, replacing the deprecated SSE transport from the 2024-11-05 spec. The server exposes a single HTTP endpoint (like https://example.com/mcp) that accepts both POST and GET requests.

The client sends every JSON-RPC message as an HTTP POST to this endpoint. The server can respond in two ways: a plain JSON response for simple request/reply patterns, or an SSE stream for operations that need to send multiple messages back (progress updates, intermediate results, or server-initiated notifications). This dual-mode response is what makes the transport "streamable" rather than purely request-response.

For server-initiated communication, the client can open a persistent GET connection to the same endpoint, which the server uses to push notifications and requests without waiting for a client POST first.

Key headers:

• Accept: application/json, text/event-stream on every POST
• MCP-Session-Id on all requests after initialization
• MCP-Protocol-Version to declare the negotiated spec version

When to use which:

If the person running the AI client also controls the machine the server runs on, use stdio. If the server needs to be accessed over a network, whether by multiple clients, from different machines, or as a shared service, use Streamable HTTP.

The Deprecated SSE Transport

The original MCP spec used a dual-endpoint SSE model where the client maintained a long-running GET for events and sent commands via POST to a separate endpoint. This created infrastructure headaches: corporate firewalls blocked SSE connections, load balancers struggled with sticky sessions, and connection drops killed entire sessions. Streamable HTTP solved these problems by consolidating everything into one endpoint with optional streaming. Legacy SSE servers still work, but new implementations should use Streamable HTTP.

Give your agents a production-ready MCP workspace

Fast.io exposes Streamable HTTP at /mcp with 19 consolidated tools for storage, AI, and collaboration. Free 50GB plan, no credit card, ready for your next integration.

Sign Up Free

An MCP session has three phases: initialization, operation, and shutdown. Understanding this lifecycle is critical for building servers that behave correctly under real-world conditions.

Initialization The client sends an InitializeRequest with its protocol version, capabilities, and client metadata. The server responds with its own capabilities and a negotiated protocol version. If the server uses Streamable HTTP, it can include an MCP-Session-Id header in this response to establish a stateful session. The client then sends an InitializedNotification to confirm the handshake, and the session enters the operational phase.

Operation During operation, both sides exchange messages according to their declared capabilities. The client sends tool calls, resource reads, and prompt requests. The server responds and can also initiate its own requests, like asking the client to perform LLM sampling or requesting user input through elicitation.

Sessions are stateful. The server may maintain context between requests: an open database connection, a cached file index, or accumulated conversation state. This statefulness is a deliberate design choice. It enables servers to provide richer context without re-processing on every request, but it also means you need to think about session affinity and cleanup.

Shutdown

The client terminates the session by closing the connection (stdin close for stdio, HTTP DELETE for Streamable HTTP). Servers should handle abrupt disconnections gracefully, cleaning up resources without requiring an explicit shutdown message. For Streamable HTTP, the server can also expire sessions unilaterally, responding with HTTP 404 to force the client to reinitialize.

Resumability

Streamable HTTP supports connection resumption through SSE event IDs. The server assigns an ID to each SSE event, and if the connection drops, the client can reconnect with a Last-Event-ID header. The server then replays missed messages from that point. This is optional but important for long-running operations where network interruptions are likely. Event IDs are per-stream, so the server only replays messages from the specific stream that was interrupted.

Moving an MCP server from local development to production introduces challenges around concurrency, state management, and operational visibility.

Stateless vs. Stateful Server Design

The simplest production pattern is a stateless server where each HTTP request is self-contained. This works well for tool-only servers that execute discrete operations (API calls, database queries, file transformations). Stateless servers scale horizontally behind any HTTP load balancer without session affinity concerns.

Stateful servers, which maintain session context between requests, need more infrastructure planning. You can either pin sessions to specific instances (using sticky sessions in your load balancer) or externalize state into a shared store like Redis or a database. The 2026 MCP roadmap explicitly targets making stateless operation easier, recognizing that most production deployments benefit from horizontal scaling over session stickiness.

Horizontal Scaling

Running multiple server instances behind a load balancer is the standard approach for handling concurrent agents. For Streamable HTTP servers, each tool call arrives as an independent HTTP POST, making load distribution straightforward. Round-robin or least-connections routing works for stateless servers. Stateful servers need session affinity based on the MCP-Session-Id header.

Container orchestration platforms (Kubernetes, AWS ECS, Google Cloud Run) handle the mechanics of scaling: health checks, auto-scaling based on CPU or request rate, rolling deployments, and fault isolation. The key consideration for MCP is matching your auto-scaling metric to your workload. CPU-bound servers (parsing, image processing) should scale on CPU utilization. I/O-bound servers (API calls, database queries) should scale on request concurrency.

Security for Remote Servers

Local stdio servers inherit OS-level process isolation. Remote servers need explicit authentication and authorization. The MCP specification recommends OAuth 2.1 with PKCE for browser-based flows, and the spec requires servers to validate the Origin header on all incoming connections to prevent DNS rebinding attacks. Locally-bound servers should listen on 127.0.0.1, not 0.0.0.0.

Beyond authentication, production servers need input validation on tool parameters, rate limiting per client or session, and audit logging of all tool invocations. Treat every tool call as untrusted input, because the LLM is choosing what to call based on potentially manipulated context.

Observability

MCP servers in production need the same observability as any microservice: request latency, error rates, and throughput. But agent workloads have additional metrics worth tracking: tool call frequency by type, session duration, capability negotiation failures, and SSE stream reconnection rates. OpenTelemetry tracing across the host-client-server boundary gives you end-to-end visibility into how long a tool call takes from the user's perspective, not just server-side processing time.

Gateway Pattern

For organizations running many MCP servers, a gateway layer provides centralized authentication, rate limiting, and routing. The gateway terminates TLS, validates tokens, and forwards requests to the appropriate backend server based on the tool or resource being requested. This mirrors the API gateway pattern common in microservice architectures and keeps individual server implementations simple.

Fast.io runs a production MCP server that demonstrates these architectural patterns in practice. The server exposes Streamable HTTP at /mcp and maintains legacy SSE at /sse for backward compatibility. It uses a consolidated tool design with 19 tools covering workspace operations, file storage, AI features, workflow primitives, and collaboration, rather than splitting each operation into a separate server.

The server handles authentication through API keys and PKCE-based OAuth for browser flows. Sessions maintain state for workspace context and Intelligence Mode queries, where the server indexes files for semantic search and citation-backed RAG chat. This means an agent can upload documents, enable Intelligence on a workspace, and then ask questions across the entire file set within the same session.

For teams building agent systems, Fast.io's architecture solves the "where do agent outputs go?" problem. Agents write files into shared workspaces that humans access through the same UI. When the agent's work is done, ownership transfer lets it hand the entire workspace to a human, keeping admin access for future updates. This bridges the gap between agent execution and human review without requiring a separate storage layer.

The free agent plan includes 50GB storage, 5,000 monthly credits, and 5 workspaces with no credit card required. That is enough to prototype MCP integrations, test multi-agent workflows, and evaluate whether the architecture fits your production needs before committing to a paid tier.

Other production MCP servers take different approaches. Filesystem servers typically use stdio for direct local access. Database connectors often run as sidecar containers alongside the database. API integration servers frequently deploy as serverless functions on platforms like Cloud Run or Lambda, where each invocation is stateless and scales automatically. The right architecture depends on your server's domain, your scaling requirements, and whether your clients are local or remote.
