Cloudflare Upload Limits: Plan Caps, Error 413, and Workarounds

The Cloudflare upload limit restricts the maximum client request body size that passes through Cloudflare proxy network: 100 MB for Free and Pro tiers, 200 MB for Business, and 500 MB by default on Enterprise. According to official Cloudflare documentation, any incoming HTTP request that exceeds the plan threshold is rejected at the network edge with an HTTP 413 status code before traversing to the origin server.

Cloudflare enforces these limits on the raw HTTP request body. When a browser, mobile application, or automated client issues an HTTP POST, PUT, or PATCH request containing file data or JSON payloads, Cloudflare edge servers inspect the Content-Length header and incoming byte stream. If the payload surpasses the plan ceiling, Cloudflare drops the connection immediately.

Understanding these boundaries is essential when designing web ingestion pipelines, media platforms, and data synchronization services. While standard file attachments fit easily within default proxy thresholds, workflows break down quickly when users upload raw video footage, database dumps, software installers, or machine learning datasets.

Request Body Versus Response Body Boundaries

A common misconception among developers is that Cloudflare limits the size of files that can be downloaded from an origin server. The upload limit applies strictly to the client request body, meaning Cloudflare does not restrict the size of HTTP response bodies streamed back from your origin application.

An application can stream multi-gigabyte files back to a user through Cloudflare proxy without triggering an upload size error. However, edge caching rules introduce separate boundaries. Assets exceeding Cloudflare edge caching thresholds pass through the network as uncached streams directly from the origin, consuming origin bandwidth rather than serving from edge cache points of presence.

Cloudflare Workers and Cloudflare Pages File Size Ceilings

Developers deploying serverless applications on Cloudflare must also account for product-specific upload boundaries:

• Cloudflare Workers: When an incoming request targets a Cloudflare Worker, the maximum request body size matches the zone's account plan: 100 MB on Free and Pro, 200 MB on Business, and 500 MB by default on Enterprise. Attempting to post a larger payload to a Worker route returns HTTP 413 before the Worker script executes.
• Cloudflare Pages: Cloudflare Pages enforces a strict maximum file size of 25 MiB for any individual static site asset. If a deployment contains a static asset larger than the platform limit, the Pages build pipeline rejects the asset. Cloudflare recommends hosting assets larger than 25 MiB in external object storage rather than within the static Pages repository.

• Notion File Upload Limits: Size Caps by Plan and Large-File WorkaroundsNotion limits individual file uploads to 5MB on the Free plan and provides unlimited file uploads with a 5GB maximum...
• AWS Lambda File Size Limits: Payload, Package, and Ephemeral Storage CapsAn AWS Lambda file size limit encompasses the execution constraints of AWS Lambda functions, specifically the 50MB...
• How to Connect Open WebUI to SharePoint via MCPOpen WebUI SharePoint integration connects self-hosted AI models to Microsoft SharePoint document libraries via the...
• Airtable Attachment Limits: File Sizes, Base Storage, and WorkaroundsThe Airtable attachment limit framework caps individual file uploads at 5 GB across all subscription tiers, while...
• ChatGPT Plus Upload Limit: File Size, Count, and Rolling CapsThe ChatGPT Plus upload limit caps subscribers at `80` file uploads every 3 hours, a `512 MB` file ceiling, and a...
• FastAPI Upload File Size Limits: Memory Spooling, Middleware, and Direct StorageFastAPI imposes no native file size limit, but Starlette spools multipart uploads in memory up to `1,048,576 bytes`...

More on this subject: Agent File and Document Workflows (269 guides)

HTTP status code 413, defined in RFC 9110 as "Payload Too Large" and historically labeled "Request Entity Too Large", indicates that the receiving web server refuses to process a request because the request payload exceeds configured limits. When operating behind Cloudflare, an HTTP 413 error can originate from two completely different infrastructure layers: the Cloudflare edge proxy or your origin web server.

Diagnosing the exact origin of an HTTP 413 error determines how you resolve it.

Edge Rejection Versus Origin Rejection

When Cloudflare edge drops an oversized upload, the rejection occurs entirely within Cloudflare global network:

1. Edge Rejection: The client initiates an upload exceeding the zone threshold (for example, a 120 MB file on a Free plan). Cloudflare edge proxy reads the incoming headers, identifies that the payload exceeds 100 MB, and immediately sends an HTTP 413 response. The connection closes, and zero bytes reach your origin server. Your origin access logs will not record any entry for this request. The response headers include Server: cloudflare and a unique cf-ray identifier.
2. Origin Rejection: If your Cloudflare plan allows the upload (for example, a 150 MB file on a Business plan) or if traffic bypasses the proxy, Cloudflare forwards the stream to your origin server. If your origin web server (such as Nginx, Apache, or Caddy) has a lower request body ceiling, the origin rejects the upload and returns an HTTP 413 error back through Cloudflare to the client.

To verify whether Cloudflare or your origin server generates the 413 error, inspect the response headers using a command-line client:

curl -v -X POST https://example.com/api/upload         -H "Content-Type: application/octet-stream"         --data-binary "@dataset-archive.zip"

If the response body displays the default Cloudflare error page with text reading "Error 413: Request Entity Too Large" and includes a Cloudflare Ray ID, the proxy edge terminated the transfer. If the response displays a raw Nginx or Apache error page, your origin server rejected the payload.

Connection Timeouts and Latency Failures

In addition to hard file size limits, very large uploads introduce connection timeout risks. Cloudflare enforces standard HTTP request timeouts between the edge and the origin. If an upload connection stalls or if the origin takes longer than 100 seconds to respond after receiving headers, Cloudflare terminates the connection with an HTTP 524 Gateway Timeout error.

On slower network connections, uploading a large archive can take several minutes. Even when an upload remains strictly under the plan tier cap, TCP connection drops or origin read timeouts can abort the transfer mid-stream. Applications handling substantial uploads require fault-tolerant transfer mechanics.

When application requirements dictate transferring files that exceed Cloudflare upload limits, engineering teams use three proven architectural strategies: client-side chunked uploads, unproxied DNS subdomains, or direct-to-storage presigned uploads. Upgrading to an Enterprise plan is also an option, but technical workarounds allow teams to transfer large payloads reliably on any plan.

1. Slicing Files with Client-Side Chunked Uploads

Client-side chunking is the most resilient approach for uploading large files through Cloudflare proxy. Instead of sending a multi-gigabyte file in a single monolithic HTTP request, the client application divides the file into smaller byte chunks, uploads each chunk sequentially or in parallel, and reassembles the complete file on the server.

Because each individual chunk measures between 5 MB and 20 MB, every HTTP request stays well below the 100 MB Cloudflare ceiling.

Here is an implementation using the browser standard HTML5 File API and Blob.slice():

async function uploadLargeFileInChunks(file, targetUrl) {
  const CHUNK_SIZE = 10 * 1024 * 1024; // 10 MB per chunk
  const totalChunks = Math.ceil(file.size / CHUNK_SIZE);
  const fileId = `${Date.now()}-${file.name.replace(/[^a-zA-Z0-9.-]/g, "_")}`;
  for (let chunkIndex = 0; chunkIndex < totalChunks; chunkIndex++) {
    const start = chunkIndex * CHUNK_SIZE;
    const end = Math.min(start + CHUNK_SIZE, file.size);
    const chunkBlob = file.slice(start, end);
    const response = await fetch(targetUrl, {
      method: "POST",
      headers: {
        "Content-Type": "application/octet-stream",
        "X-Upload-File-Id": fileId,
        "X-Upload-Chunk-Index": chunkIndex.toString(),
        "X-Upload-Total-Chunks": totalChunks.toString(),
        "X-Upload-File-Name": encodeURIComponent(file.name),
      },
      body: chunkBlob,
    });
    if (!response.ok) {
      throw new Error(`Chunk ${chunkIndex + 1}/${totalChunks} failed with status ${response.status}`);
    }
  }
  return { fileId, status: "completed" };
}

Chunked uploads offer multiple advantages beyond bypassing proxy limits:

• Pause and Resume: If a network connection drops during a multi-gigabyte transfer, the client only re-transmits the failed chunk rather than restarting the entire file.
• Progress Tracking: Applications can calculate precise upload percentages based on confirmed chunk responses.
• Edge Compatibility: Every request conforms to standard Cloudflare proxy thresholds, preserving DDoS protection and Web Application Firewall (WAF) filtering.

Open-source upload protocols such as Tus (tus.io) and Uppy implement standardized chunking, pause, and resume mechanics across web and mobile clients.

2. The DNS-Only Subdomain Pattern

If rewriting client code to support chunked uploads is impractical, teams can bypass the Cloudflare proxy entirely using a dedicated subdomain.

In the Cloudflare dashboard under DNS > Records, create a new A or CNAME record specifically for file ingestion (for example, upload.example.com or direct.example.com). Set the proxy status toggle to DNS only (represented by a grey cloud icon) rather than Proxied (orange cloud).

When users or client applications upload files to https://upload.example.com/api/upload, traffic routes directly to the origin server IP address. Because traffic never traverses the Cloudflare proxy edge, the 100 MB upload limit does not apply.

To mitigate the security risks of an unproxied subdomain, configure origin firewall rules (such as iptables or cloud security groups) to restrict the DNS-only hostname to authenticated API clients or specific internal network ranges.

3. Direct-to-Storage Architecture with Presigned URLs

The recommended architectural pattern for modern web applications decouples file storage from application servers. Instead of routing multi-gigabyte files through web servers and edge proxies, clients upload directly to cloud object storage using temporary presigned URLs.

The workflow executes in three steps:

1. Request Presigned URL: The client sends a lightweight JSON request to your API (POST /api/uploads/request-url) describing the file name, size, and MIME type.
2. Generate Signed Target: Your backend application validates authentication and calls the storage provider API to generate a temporary presigned upload URL with an expiration window (such as 15 minutes).
3. Direct Upload: The client uploads the binary payload directly to the storage bucket endpoint using HTTP PUT.

Because the upload target is an object storage bucket (such as AWS S3, Cloudflare R2, or Google Cloud Storage), the upload completely bypasses your application server and the 100 MB proxy limit. Cloudflare R2 supports massive multi-terabyte objects via S3-compatible multipart uploads, and charges zero egress fees.

Store and Query Large Datasets Without Proxy Limits

Upload multi-gigabyte files into shared workspaces where AI agents search indexed content through remote MCP instead of hitting edge proxy caps. Monthly plans start with a 30-day free trial.

Start 30-Day Trial

If an Enterprise organization raises their Cloudflare upload limit to 500 MB or 2 GB, or if a team routes uploads through a DNS-only subdomain, the origin web servers must be explicitly configured to accept larger payloads. By default, most web servers and reverse proxies enforce conservative body size caps that reject large files with their own local HTTP 413 errors.

Nginx Configuration

In Nginx, the client_max_body_size directive controls the maximum allowed size of a client request body. The default value is 1m (1 megabyte).

To support large uploads, adjust the directive inside the http, server, or specific upload location block in /etc/nginx/nginx.conf:

http {
    client_max_body_size 500M;
    client_body_buffer_size 256k;
    client_body_timeout 300s;
    send_timeout 300s;
    server {
        listen 443 ssl http2;
        server_name upload.example.com;
        location /api/upload {
            proxy_pass http://backend_upstream;
            proxy_read_timeout 300s;
            proxy_connect_timeout 75s;
            proxy_send_timeout 300s;
            proxy_request_buffering off;
            proxy_http_version 1.1;
        }
    }
}

Disabling proxy_request_buffering instructs Nginx to stream incoming bytes directly to the upstream application as they arrive, reducing disk I/O bottlenecks and memory usage during multi-hundred-megabyte transfers.

Apache Configuration

In Apache HTTP Server, the LimitRequestBody directive specifies the maximum number of bytes allowed in a request body, accepting values up to two gigabytes or zero for unlimited.

Add or adjust the directive in your VirtualHost configuration or .htaccess file:

<VirtualHost *:443>
    ServerName upload.example.com
    LimitRequestBody 524288000
    TimeOut 300
</VirtualHost>

Application Runtime Configurations

Behind the reverse proxy, application runtimes also enforce payload limits:

• Node.js and Express: If an application parses JSON or URL-encoded bodies, the default body-parser limit is 100 KB. Increase the threshold explicitly:

  app.use(express.json({ limit: "100mb" }));
  app.use(express.urlencoded({ limit: "100mb", extended: true }));


For binary multipart file uploads, avoid loading entire payloads into memory. Use streaming middleware like busboy or configure multer with disk storage and explicit file size boundaries.

• PHP Runtime (php.ini): PHP enforces upload caps through multiple interconnected directives. To allow 500 MB uploads, adjust all four values:

  upload_max_filesize = 500M
  post_max_size = 512M
  memory_limit = 512M
  max_execution_time = 300
  max_input_time = 300


The post_max_size setting must always be larger than upload_max_filesize to accommodate multipart headers and accompanying form data.
